Flatbed semi trailer trains compared to regular cars
1) High transportation efficiency: the loading quality of general all-trailer trains is 1-2 times that of ordinary freight cars;
2) Low manufacturing cost: Generally, the manufacturing cost of a full trailer is 50%-60% lower than that of a truck of the same tonnage;
3) Low fuel consumption: the fuel consumption per 100 ton-kilometer is 40% lower than that of a single truck;
4) Simple structure, convenient maintenance, low maintenance cost, and can be towed without modification for general trucks;
5) After it can be removed and hung, it can be used as a storage unit for a long time.
The flatbed semi trailer itself has no power and can be pulled by forklifts and tractors.
Because flatbed trailers have these advantages over ordinary cars in transportation, these flatbed trailers are slowly being widely used in Malaysia
Flatbed semi trailer use
Flatbed semi trailer is a full trailer, mainly used for turnover transportation in factories, docks, ports, airports and other fields, not for long-distance transportation on expressways. The flatbed semi trailer itself has no power and can be pulled by forklifts and tractors.
12m heavy duty flatbed semi trailer
This 12m heavy duty 20t heavy flatbed semi trailer is a towing vehicle used in factories, logistics and ports. Load capacity, main dimensions can be customized according to customer needs. Good bending performance, the body is not easy to bend down. The traction frame reduces the impact force when the vehicle starts and stops, effectively protects the safety of the vehicle, and is equipped with a slewing bearing and turntable steering. The front suspension is steered, the rear suspension is oriented, the rear suspension is double suspension, and the high-strength buffer spring can still be used on uneven roads during transportation. Equipped with insertion holes, it can transport cylindrical goods such as round steel and round wood. It has the advantages of simple structure, convenient application, convenient maintenance, large bearing capacity and long service life. It is widely used in many industries such as machinery, metallurgy, warehousing and transportation, and the combination of tractors makes the flat plate play an important role in various fields.
Types of tires: tires: special tires for fflatbed semi trailer (iron core rubber solid tires, white non-marking pneumatic tires or other special tires)
Steering form: front suspension steering, rear suspension orientation, suspension system, high-strength slewing bearing
Shock absorption form: bridge spring steel plate shock absorption for engineering vehicles
Traction form: rectangular tube traction frame (with spring anti-fall device and buffer device) or other customized traction frame,
Surface treatment: rust removal, scale removal, anti-rust paint, topcoat treatment.
Processing method: Custom fflatbed semi trailer, OEM processing, non-standard customization.
12m flatbed semi trailer can carry about 10t
1. Flatbed trailers generally use inflatable solid tires, and there is no danger of tire breakage or puncture.
2. The flatbed trailer has a low board height and a large loading capacity.
3. The flatbed trailer is of reliable quality, safe, simple and durable.
4. The flatbed trailer has high transfer and translation efficiency, which greatly reduces manpower consumption.
5. The flatbed trailer is environmentally friendly and has little pollution. The flatbed semi trailer is mostly used for carrying people and objects. When driving, hang the "car trip" tied between the two handlebars on your shoulders, hold it with both hands, and lean forward a little to pull the car on the road. When encountering an uphill or slippery road, the person following the car can tie a rope around the shoulder on the right side of the handlebar to pull the car or push it forward.
12m heavy duty flatbed semi trailer quality assurance and after sales promise for Malaysia:
(1) We give the following guarantees to the flatbed semi trailer products we sell:
1. Quality guarantee period: The product is one year from the date of delivery.
2. Scope of Guarantee: According to relevant national quality regulations, during the quality assurance period, the user shall conscientiously perform and strictly abide by the relevant correct operation, safety instructions and maintenance requirements in the "Operation Manual". In the event of a failure, the company is responsible for free replacement of damaged parts and free maintenance.
If you purchase a trailer, we can sell it to you from India. Provide complete after-sales service.
16m heavy duty flatbed semi trailer
This 16m heavy duty 50t flatbed semi trailer is a towing vehicle used in factories, logistics and ports. Load capacity, main dimensions can be customized according to customer needs. Good bending performance, the body is not easy to bend down. The traction frame reduces the impact force when the vehicle starts and stops, effectively protects the safety of the vehicle and turns the turntable. The front suspension is steered, the rear suspension is oriented, the rear suspension is a double suspension, and the high-strength buffer spring can still be used on uneven roads during transportation. Equipped with insertion holes, it can transport cylindrical goods such as round steel and round wood. It has the advantages of simple structure, convenient application, convenient maintenance, large bearing capacity and long service life. It is widely used in many industries such as machinery, metallurgy, warehousing and transportation, and the combination of tractors makes the flat plate play an important role in various fields.
16m heavy duty flatbed semi trailer parameters:
Tires: flatbed semi trailer special tires (iron core rubber solid tires, white non-marking pneumatic tires or other special tires)
Steering form: front suspension steering, rear suspension oriented
Shock absorption form: high-strength spring shock absorption
Traction form: rectangular tube tow frame (with spring anti-fall device and buffer device) or other customized tow frame
Surface treatment: rust removal, scale removal, anti-rust paint, topcoat treatment.
Processing method: Custom flatbed semi trailer, OEM processing, non-standard customization.
Length*width*height = volume. A 16-meter flat plate can generally hold 170 square meters without being super wide or super high. It is calculated by 2.4 meters wide, 13 meters long, and even the car body installed to 4.5 meters high.
16m heavy-duty flatbed semi trailer quality assurance and after-sales commitment:
(1) We give the following guarantees to the fflatbed semi trailer products we sell:
1. Quality guarantee period: The product is one year from the date of delivery.
2. Scope of Guarantee: According to relevant national quality regulations, during the quality assurance period, the user shall conscientiously perform and strictly abide by the relevant correct operation, safety instructions and maintenance requirements in the "Operation Manual". In the event of a failure, the company is responsible for free replacement of damaged parts and free maintenance.
(2) After-sales service response time:
Under normal circumstances, our company promises to respond within 2 hours after receiving the customer's call, fax or email. If necessary, our company's after-sales service engineer or local special maintenance department will arrive at the scene within 4 hours (customers in the same city), or According to the fastest arrival time by train (car, such as no train) (for non-local customers).
Due to different production batches and specific models, the above pictures are for reference only. For details, please contact our sales staff for specific verification.
If you want to be our trailer agent or distributor. You buy flatbed trailers for sale in bulk in India, we provide the most advantageous price.
Flatbed semi trailer features
1. The use of high elastic solid tires can enhance the carrying capacity of the trailer and improve the service life.
It can reduce the damage to the goods caused by road bumps during driving; press-fit tires are used, because the tire height is low,
Strengthen the stability of the vehicle and the carrying capacity of the trailer. Especially suitable for the handling of bulk molds.
2. It adopts double suspension structure, suspension frame, and automatic swing adjustment of the axle to ensure that it is on the convex and concave ground, to ensure that the car body is level and the tire force is balanced. Improve safety during transportation.
3. The material of the pin shaft of the connecting part is made of alloy steel, which is treated by a special process to improve the service life.
4. It adopts the form of double-track machine slewing mechanism, and the performance is more stable.
5. The traction faucet can be adjusted and fixed up and down, and only simple adjustment is required when traction heads or forklifts of different tonnage are towing.
Flatbed semi trailer performance
1. Double-spring buffer traction mechanism, there is a buffer when the flatbed semi trailer starts or brakes suddenly to avoid damage to the goods
2. The steering mechanism is Shanghai Industrial Machinery slewing assembly (excavator hook arm slewing assembly), so there is no need to worry about damage for ten years.
3. The traction cage can be adjusted and fixed up and down, and it is only necessary to adjust the traction head or forklift of different tonnages.
4. The suspension frame, compared with the traditional hard connection (welding), reduces the long-term stress damage of the car body and has a longer service life.
5. The axle is automatically oscillated and adjusted, and the convex and concave ground ensures the level of the board and the balanced force on the tires.
6. The front and rear wheel sets can be equipped with spring steel sheet shock absorbers to reduce the damage to the goods due to bumps
7. Adopt the brand engineering solid tires that are recognized by domestic engineering vehicles, with high elasticity, wear resistance,
8. 180-degree swivel frame, minimum turning radius (180-degree turn in place)
9. The semi trailer is equipped with a universal connector, which is very flexible in operation.
