Gooseneck semi-trailer is widely used to carry goods for different purposes. 40 Ft Gooseneck Trailer Price is $ 8,000 - $ 15,000. It is suitable for the transportation of various mechanical equipment, large objects, highway construction equipment, large tanks, power station equipment, and all kinds of steel. Gooseneck trailers have flatbed type, concave beam type and tire exposed structure. The longitudinal beam uses flat type or gooseneck type. Its frame is in step shape and the longitudinal beam section is I-shaped, which provides extremely high rigidity and strength.
The main platform of the frame is very low, which ensures the stability during transportation and is suitable for carrying all kinds of construction machinery, large equipment and steel. The three-axis balanced flexible rigid suspension is normally used and a mass balance weight is installed between the front and rear leaf springs. This setup can change the deflection of the front and rear leaf springs by the same amount and balance the force on the rear axle.
40 foot gooseneck trailer is widely used because it’s efficient and easy to use. The whole trailer has advanced computer-aided design software to optimize its functionality, which makes its application flexible and diverse. The bearing surface of the frame can be customized according to the user's requirements for their transportation of various special goods.
Gooseneck trailers with better structure are relatively more expensive. The price is only an externalization of the excellent structure. When we purchase a 40-foot gooseneck trailer, we can't just look at the price. Besides, the price of 40 Foot Gooseneck Trailer is really not high, the highest price is only $15,000
Not only skeleton trailer can be customized as gooseneck structure, so can flatbed trailers. The skeleton trailer is welded by the longitudinal beam, cross beam and front and rear beams. The longitudinal beam is made of high-quality steel plate 16Mn submerged arc welded into I-shape with dimensions of 450 and 500. The cross beam is stamped into groove shape with high-quality steel plate, and the front and rear end beams are welded rectangular sections.
The middle container locking device is equipped with an integral long beam to improve the bearing capacity of the container locking device. The difference between flatbed trailer and skeleton trialer is that the flatbed trailer is added with frame and patterned steel floor. The frame paint is usually treated with shot blasting. The whole frame is assembled and welded onto a special positioning platform. It has very practical structure, high strength and pleasant appearance. A container tightening device is installed on the frame, which can load two kinds of standard containers: one 40 foot container or two 20 foot containers. The four container tightening devices at the front and rear ends are fixed structure and the middle container tightening device is hidden. When loading containers, the locking device of the intermediate container can be lowered below the suface of the loading platform as needed.
40 Foot Gooseneck Trailer Price starts at $8,000. Due to the difference in design and process, the Gooseneck Trailer Price is also different. The overall 40 ft Trailer Price needs to be calculated with our sales experts.
Mechanical bearing device also called landing gear is always installed. Typical brands include Baohua 12t and 20t, Fuhua 13T, JOST and so on. Its function is to support the ground and bear the front weight of the trailer when the tractor or truck head is separated from the trailer. There are two kinds of landing gears: single acting and linkage, both of which are mainly composed of supporting disc, screw transmission mechanism, reduction gearbox and joystick. The suspension device includes single axle suspension, double axle suspension, and three axle suspension. The semi-trailer is equipped with two sets of spare wheel frames, which are installed on the left and right sides of the trailer frame respectively. A spare wheel lifter is also available to make the wheel changing process much easier.
For more information about 40 Foot Gooseneck Trailer Price, also need to consult our experts. Different configurations 40 Foot Gooseneck Trailer Price will be different.
